Product Details

Multiple functions can be implemented on a single device. The front end is equipped with a loading device for shoveling materials, while the rear end of the excavation device can be used to dig soil, rocks, etc.

By replacing different working devices, such as crushing hammers, forks, grabs, etc., the equipment can adapt to a variety of construction needs, including excavation, loading and unloading, etc., which greatly improves the efficiency of the machine, and is suitable for small earthwork engineering, landscaping, agricultural orchard planting, concrete crushing and other construction sites with small space.

It is easy to operate, strong in power, and realizes mutual supply of hydraulic power for excavation and loading. It can be flexibly moved on various terrains, which improves construction efficiency.

The seat rotates to allow the operator to switch between different working ends, and the seat belt increases the safety of operation. The 360° swivel seat with suspension shock absorption improves the comfort of the driver.

The GWZ10-20 is a compact backhoe loader with a balanced design for digging, loading, and material handling. Below is a summarized breakdown of its key specifications:

General Specifications

• Dimensions (L×W×H): 5500 × 1720 × 2650 mm
• Operating Weight: 3400 kg
• Rated Load Capacity: 1500 kg
• Rated Power: 40 kW (55 hp)
• Engine:
  • Diesel, 4-cylinder, 4-stroke, water-cooled
  • Optional: EPA/EU5-compliant engine available

Backhoe Performance

• Bucket Capacity: 0.1 m³
• Max Digging Depth: 2000 mm
• Max Digging Height: 3300 mm
• Max Digging Radius: 2900 mm
• Max Dumping Height: 1850 mm
• Max Breakout Force: 25 kN (~2550 kg)

Loader Performance

• Bucket Capacity: 0.5 m³
• Max Dumping Height: 2800 mm
• Max Dumping Distance: 800 mm
• Max Breakout Force: 36 kN (~3672 kg)

Mobility & Transmission

• Travel Speed: 0–26 km/h
• Gradeability: 30°
• Min. Turning Radius: 3500 mm
• Transmission Type: Hydraulic
• Braking System: Air-assisted

Tires & Stability

• Tire Model: 20.5-16
• Tire Pressure: 250 kPa
• Wheel Tread: 1630 mm
• Wheelbase: 2670 mm

Hydraulics & Comfort

• Working Pressure: 16 MPa
• Optional Comfort Features: Available

Key Features

• Versatile for construction, agriculture, and utility work.
• Optional EPA/EU5 engine for stricter emission compliance.
• Hydraulic transmission for smooth operation.

This model is suitable for small to medium-scale projects requiring both digging and loading capabilities.

Other Optional Accessories

WORKSHOP

Warranty

♦ 12-month warranty.

Guarantee

♦ Engine and all parts are 100% genuine and certificate is with it.

♦ Machine is verified and inspection and adjustments are completed as well as verified in writing.

♦ Testing is done and results are verified in writing.

After-sales Support

♦ 24/7 service by chat online and phone.

♦ Lifelong and free technical support.

♦ Free parts will be expressed to you under warranty if parts of the machine are damaged.

♦ Free troubleshooting.
